AC7012
- Material Polypropylene
- Material sealing gasket TPE
- Temp. range min -30 °C
- Temp. range max 100 °C
- Temperatures during install. -5 °C - 60 °C
- Protection class IP66
- Glow wire test 750 °C
- Voltage 400 V
- Rated current / A (Terminal) 24 A
- Rated cross section 2,5 mm²
- Terminals/poles 5-pole, 2,5mm²
- Fixing 2 internal openings
- Ø cable diameter min 3 mm
- Ø cable diameter max 14 mm
- External dimensions LxWxH 76 x 76 x 51mm
- Product Color RAL 9001
| Amps | 24A |
|---|---|
| Colour | White |
| Dimensions hxwxd mm | 76 x 76 x 51mm |
