AC33894
- 5 way single pole terminal block
- Rating: 100A 230VAC
- Can accept up to 5 conductors (2.5-35mm²)
- Top and bottom cable entry points
- Dual screw terminations (4mm allen key) for secure
- connection of conductors
- Terminal tightening torque: 3Nm
- Modular construction – terminal blocks can be close
- coupled for ease of installation
- Secure cover (3mm allen key) with wire locking capability
- Retained shutters for blanking of unused cable entries
- 960°C glow wire tested
- Ingress protection: IP20
- Applicable standards: BS EN60998-1 / BS EN 60998-2-1
| Colour | Grey |
|---|---|
| Gang | 5 |
| Ip rating | IP20 |
| Flipbook URL | Interactive Trade Catalogue |
| Current rating | 100 A |
| Mounting type | Wall |
| Number of poles | 1P |
| Voltage rating | 230|400 V |
| Product weight | 0.17 kg |
